StarTech.com CDP2MDPMM1MB 1m / 3.3ft USB-C to Mini DisplayPort
This USB-C™ to Mini DisplayPort adapter cable offers a convenient solution for directly connecting your DisplayPort over USB Type-C™ device to your Mini DP monitor. The adapter offers a connection distance of up to 1 m (3 ft.) and works with USB-C devices that support DP Alt Mode, such as the MacBook, Chromebook Pixel™ and Dell™ XPS™ models 15 and 13. It's also compatible with Thunderbolt™ 3 ports.
Clutter-free installation
At 1 m (3 ft.) in length, this adapter cable delivers a direct connection that eliminates excess adapters and cabling, ensuring a tidy, professional installation.
Astonishing picture quality
At four times the resolution of high-definition 1080p, you’ll be amazed at the picture quality of a 4K 60Hz monitor or television. This adapter cable lets you harness the video capabilities that are built into your USB Type-C connection, to deliver the astonishing quality of Ultra HD to your 4K display.
Plus, the adapter is still compatible with lower display resolutions, such as 1080p, which makes it a great accessory for your current home, office or other HD work environment, while future-proofing for 4K 60Hz implementation.
Applications
- Connect your BYOD MacBook or Dell XPS with USB-C to a provided Mini DisplayPort monitor at work
- Connect an mDP display to your USB-C laptop to use as a secondary display
- Connect a secondary USB-C laptop to the mDP port on your 2009 or 2010 iMac, to use your iMac as a monitor
HARDWARE
Adapter Style
Cable Adapters
AV Input
USB Type-C
AV Output
Mini-DisplayPort
Chipset ID
STMicroelectronics - STM32F072CBU6
Ports
1
PERFORMANCE
Audio Specifications
7.1 surround sound
Maximum Digital Resolutions
3840x2160 @ 60 Hz
Supported Resolutions
1024x768 1280x720 (High-definition 720p) 1920x1080 (High-definition 1080p) 1920x1200 2560x1440 2560x1600 3840x2160 (Ultra HD 4K)
Wide Screen Supported
Yes
CONNECTOR(S)
Connector A
1 - USB-C (24 pin) DisplayPort Alt Mode Male Input
Connector B
1 - Mini-DisplayPort (20 pin) Male Output
SPECIAL NOTES / REQUIREMENTS
Note
Your USB-C port must support DisplayPort over USB-C (DP Alt mode) in order to work with this adapter.
ENVIRONMENTAL
Humidity
25%-60%RH
Operating Temperature
5°C to 35°C (41°F to 95°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
PHYSICAL CHARACTERISTICS
Cable Length
3.3 ft [1 m]
Color
Black
Product Height
0.4 in [10 mm]
Product Length
3.3 ft [1 m]
Product Weight
0.9 oz [25 g]
Product Width
0.8 in [20 mm]
WHAT'S IN THE BOX
Included in Package
1 - USB-C to Mini DisplayPort cable
