TP-Link Archer C20 Wi-Fi Router
http://www.tp-link.com.au/products/details/cat-9_Archer-C20.html
- Supports 802.11ac standard - the next generation of Wi-Fi
- Simultaneous 2.4GHz 300Mbps and 5GHz 433Mbps connections for 733Mbps of total available bandwidth
- 2 external antennas provide stable omnidirectional signal and superior wireless coverage
- USB port - share a printer locally and files & media with networked devices or remotely via FTP server
802.11ac - The Next Generation of Wi-Fi
TP-LINK's Archer C20 comes with the next generation Wi-Fi standard - 802.11ac, backward compatible with 802.11n and 3 times faster than wireless N speeds. With higher power efficiency and robust security, 802.11ac is the perfect way to accelerate a home multimedia network and solve congestion that multiple devices may cause.
733Mbps Dual Band Connections for Lag-Free Work
With 433Mbps wireless speeds over the crystal clear 5GHz band and 300Mbps over the 2.4GHz band, Archer C20 offers you the flexibility of two dedicated networks and ensures amazing wireless performance. Simple tasks such as sending e-mails or web browsing can be handled by the 2.4GHz band while bandwidth intensive tasks like online gaming or HD video streaming can be processed by the 5GHz band - all at the same time.
Stable Omnidirectional Signal and Superior Coverage
With 2 fixed external antennas combined with higher quality antenna technology, you can experience excellent wireless performance with stable signal in every direction and high speed across greater distances. This provides you with incredible wireless coverage and reliability from anywhere in your large home or office.
Technical Specs
Interface
4 10/100Mbps LAN ports
1 10/100Mbps WAN port
Button
WPS/Reset Button
Wireless On/Off Switch
Power On/Off Button
Antenna
2 × 2.4GHz Antennas
1 × 5GHz Antenna
External Power Supply
12VDC /1A
Dimensions ( W x D x H )
9.1 x 5.7 x 1.4 in. (230 x 144 x 35mm)
Antenna Type
Two dual band fixed antennas
WIRELESS FEATURES
Wireless Standards
IEEE 802.11ac/n/a 5GHz
IEEE 802.11b/g/n 2.4GHz
Frequency
2.4GHz and 5GHz
Signal Rate
5GHz: Up to 433Mbps
2.4GHz: Up to 300Mbps
Reception Sensitivity
5GHz
11a 6Mbps: -91dBm, 11a 54Mbps: -74dBm
11ac HT20: -66dBm, 11ac HT40: -64dBm, 11ac HT80: -61dBm,
11n HT20: -71dBm, 11n HT40: -69dBm
2.4GHz
11g 54M: -76dBm
11n HT20: -74dBm, 11n HT40: -71dBm
Wireless Functions
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Wireless Security
64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption
Transmission Power
CE:
<20dBm(2.4GHz)
<23dBm(5GHz)
FCC:
<30dBm
SOFTWARE FEATURES
Quality of Service
WMM, Bandwidth Control
Management
Access Control
Local Management
Remote Management
Port Forwarding
Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS
DynDns, Comexe, NO-IP
VPN Pass-Through
PPTP, L2TP, IPSec
Access Control
Parental Control, Local Management
Control, Host List,
Access Schedule, Rule Management
Firewall Security
DoS, SPI Firewall
IP Address Filtering/MAC Address Filtering/Domain Filtering
IP and MAC Address Binding
Protocols
Supports IPv4 and IPv6
USB Sharing Support
Samba(Storage)/ FTP Server/Media Server/Printer Server
Guest Network
2.4GHz guest network × 1
5GHz guest network × 1
OTHERS
Certification
CE, FCC, RoHS
Package Contents
AC750 Wireless Dual Band Router Archer C20
2 Fixed Antennas
Power Supply Unit
Resource CD
Ethernet Cable
Quick Installation Guide
Box Dimensions (W X D X H)
11.2 x 8.8 x 3.6 in. (285x223x91mm)
System Requirements
Windows 10/8.1/8/7/Vista/XP, Mac OS or Linux-based operating system
Environment
Operating Temperature: 0?~40 ? (32 ?~104?)
Storage Temperature: -40?~70 ? (-40 ?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
