The Teltonika Industrial LTE Cat 1 Gateway Board TRB145 is equipped with RS485 Interface, Digital Inputs/Outputs and micro-USB port. TRB145 compact design makes this Gateway perfect for an application where a sole gadget must be remotely controlled over RS485 interface. The TRB145 is engineered to be used in Industrial applications therefore it has a wide range of software features such as SMS control, Firewall, Open VPN, IPsec, RMS and FOTA support.
Lightweight and powerful RS485 to 4G LTE Cat1 IoT gateway. High performance paired with Linux based firmware enables quick time-to-market in the most demanding applications.
Key Features
- RS485 for industrial differential serial communication
- Wide range of power supply voltages 9 – 30V
- LTE Cat 1 for M2M/IoT communications
- Teltonika Remote Management System compatible
- Compact size, easy integration
- OpenLinux based OS allows high software customisation
Product code
TRB145101000
Mobile
LTE(Cat1)/3G/2G
SIM slot
Mini SIM (2FF)
Antenna connector
1 x SMA for LTE
RS485
Full Duplex (4 wires) and Half Duplex (2 wires), baud rate 300-115200
Input/Output
2 x Digital Input/Output (configurable)
CPU
ARM Cortex-A7 1.2 GHz CPU
RAM
128 MB (50 MB available for userspace)
Flash
512 MB (70 MB available for userspace)
Input voltage range
9 - 30 VDC
Power connector
4 pin industrial DC power socket
Optional power source
Possibility to power device over 6 pin RS485 connector’s spare terminals.
Configuration interface
Virtual NIC via Micro-USB connector
LED Indicators
Power, signal, network and data status LEDs
Operating System
Linux OS with Yocto SDK (offering high software customisation)
Network
NAT, Static/Dynamic routing, Firewall (port forward, traffic rules, custom rules), OpenVPN, DDNS ( >25 service providers supported)
RS485 related services
Modbus, Serial over IP, NTRIP
Remote management
RMS Support, FOTA support, SSH, CLI, SMS Utilities (status/configuration)
Status watchdogs
Ping reboot, periodic reboot
Additional features
Internet connectivity over USB virtual network interface
Operating temperature
-40° C to 75° C
Storage temperature
-45° C to 80° C
Operating humidity
10% to 90% non-condensing
Storage humidity
5% to 95% non-condensing
Dimensions
60 mm x 70 mm x 18 mm
Weight
29.8 g
