- Fully Complies with IEEE 802.3 802.3u and 802.3ab standards
- 5 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
- Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
- Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
- Supports MAC address auto-learning and auto-aging
- LED indicators for monitoring power link activity
- Plastic case desktop or wall-mounting design
- External power adapter supply
Standards
IEEE 802.3 IEEE 802.3u IEEE 802.3ab
Topology
Star
Protocol
CSMA/CD
Data Transfer Rate Ethernet:
10Mbps (Half Duplex) 20Mbps (Full Duplex)
Fast Ethernet:
100Mbps (Half Duplex) 200Mbps (Full Duplex)
Gigabit Ethernet:
2000Mbps (Full Duplex)
Network Media (Cable) 10Base-T:
UTP category 3 4 5 cable (maximum 100m)
EIA/TIA-568 100Ù STP (maximum 100m)
100Base-Tx: UTP category 5 5e cable (maximum 100m)
EIA/TIA-568 100Ù STP (maximum 100m)
1000Base-T: UTP category 5 5e cable (maximum 100m)
Number of Ports
5 10/100/1000Mbps Auto-Negotiation ports
LED indicators
Power Link/Act
Transfer Method
Store-and-Forward
MAC Address Learning
Automatically learning automatically Update
Frame Filtering and Forward Rate
10Mbps: 14880pps 100Mbps: 148800pps 1000Mbps: 1488000pps
Power Supply Output
9V~ 50-60Hz 1.2A
Safety & Emission
FCC CE
Dimensions (W×D×H)
7.3×5.7×1.7in.(186×146×44mm)
Environment
Operating Temperature:
0 C~40 C (32 F~104 F)
Storage Temperature:
-40 C~70 C (-40 F~158 F)
Operating Humidity:
10%~90% non-condensing
Storage humidity:
5%~95% non-condensing
