Specially designed audio architecture, dual flagship CS43198 DACs
Two flagship Cirrus Logic CS43198 chips are paired with two low-noise HiFi SGM8262 headphone amps in the DM13’s specially designed audio architecture. The combination of dual DACs and dual amplifiers allows the portable CD player to exhibit truly high-quality sound.
FIIO engineers also specially designed an output stage that better captures the sound of the DAC, with that same DAC chip controlling the volume. The DAC chip allows for a 99-level fine volume adjustment that not only achieves smooth volume changes but also makes the sound at any volume level clearer.
*Standard version cannot transmit Bluetooth.
Tiny body, enormous power
FIIO designers have combined manufacturing craftsmanship and structural design to shrink down the DM13 to be smaller than most other CD players, with dimensions of approximately 144*137*27mm (excluding feet). The DM13 also features an ESP (electronic skip protection) switch, ensuring a stable and pleasant sound experience whether you're on the go or listening while stationary.
The DM13 may be compact but packs impressive performance, distinguishing it from other similar products. It not only drives most headphones but can also connect to powered speakers or other headphone amps for an extraordinary listening experience.
Dual analog and digital outputs
The DM13 comes with 3.5mm+4.4mm headphone outputs as well as 3.5mm+4.4mm line outputs, allowing for connections to headphones or active speakers and power amplifiers.
The DM13 also features optical and coaxial digital outputs for connection to an external DAC. Moreover, it combines custom low-jitter crystal oscillators to ensure accurate synchronization of the digital clock, resulting in cleaner and more stable digital signal transmission.
USB CD ripping, more ways to play
Compared to similar levels of portable CD players, the DM13 comes with a rarely-seen function of USB CD ripping. You can rip your favorite CDs into WAV files stored on a portable storage device, making it easy to share with friends and family. The WAV music files on that portable storage device can then be easily transferred to other computers or phones, allowing you to play the music on your CDs anytime, anywhere.
*Only supports FAT32 formatted storage devices.
Gapless and smooth playback
In the early stages of designing this product, we extensively collected user feedback and overcame many challenges to carefully create a range of user-friendly and thoughtful features - including gapless playback, ability to keep favorites, and loop playback. The loop playback function supports looping on a single track, random tracks, and even on the entire CD – allowing you to customize how you want to listen.
For more impressive features, such as the custom high-contrast, long-lasting LCD display, patented desktop mode, 10 hours of playback from lithium batteries, and aptX High-Res Bluetooth transmission, please visit the product page on our website.
Colour
White (standard version only),
Power input
5VI2A (Type-C)
DAC
CS43198*2
Headphone amplifier
SGM8262*2
Display
1.5 inch LCD
Headphone outputs
Single-ended 3.5mm + balanced 4.4mm
Line outputs
3.5mm LO/COAX/OPT + 4.4mm balanced LO
Output power 1
L+R=180mW+180mW (320, THD+N < 1%/ single-ended)
Output power 2
L+R=660mW+660mW (32Q, THD+N < 1%/balanced)
Single-ended line output level
L+R=2.5Vrms+2.5Vrms
Balanced line output level
L+R=5Vrms+5Vrms
Bluetooth output codecs
apt HD/aptX Low Latency/aptX/SBC
(Bluetooth version only)
Supported CD-R formats
FLAC/WAV/WMA/AAC/MP3
(only supports CD layer of SACD discs)
SNR
=124dB (A-weighted)
Noise floor
PO: =2.4uV (A-weighted), BAL: =2.8uV (A-weighted)
THD+N
=0.0024% (1kHz/OdB @ 320)
Battery capacity
3750mAh
Battery life
=10 hours
Dimensions
About 144*137*27mm (excluding feet)
Weight
About 450g
