StarTech.com UCC-3M-10G-USB-CABLE 3m Active USB-C Cable USB 3.2 10 Gbps
UCC-3M-10G-USB-Cable
This cable is ideal for setups requiring full-featured USB-C and DP 1.4 support, such as large UHD displays/video walls, and boardroom/conference room cameras.
- Versatile Compatibility: The USB-C to C cable enables universal compatibility with USB 3.2, USB 3.0, and USB-C devices. An integrated active chipset facilitates bi-directional connectivity for convenient setup, and supports up to 10Gbps throughput without additional power or signal boosters.
- Experience 4K Video with DisplayPort 1.4 Alt Mode: The Active USB-C cable supports up to 8K 60Hz video over DisplayPort 1.4 Alt Mode with HBR3, HDR10, MST, DSC 1.2, and HDCP 2.2. It is backward compatible with DP 1.3/1.2 resolutions, including 4K 60Hz, 1440p, and 1080p.
- Full-Featured USB-C Power and Data: The long Active USB-C Cable supports a data bandwidth of up to 10 Gbps. A certified E-marker chip ensures consistent Power Delivery of up to 60W. Dock and charge a USB-C laptop, such as Apple MacBook, Lenovo ThinkPad, or Microsoft Surface using a single USB-C connection that extends beyond the length of passive cables.
- Applications: Enable full-featured USB-C and 8K DP Alt Mode video to peripheral devices up to 3m away
Ideal for larger workstations, UHD displays, and boardrooms/conference rooms
ACTIVE USB-C CABLE:
3m (9.8ft) Active USB-C cable supports bi-directional 10Gbps data, 8K video, and 60W Power Delivery beyond the length of passive cables; Ideal for USB-C monitors and devices, boardroom cameras, and connectivity in large workspaces
USB-C OVER LONGER DISTANCE:
Integrated active re-timer chipset maintains signal integrity at distances of up to 9.8ft for seamless video performance and optimal transfer rates; Certified E-marker chip for Power Delivery output to USB-C devices
FULL-FEATURED USB-C:
Supports up to 10 Gbps, 8K 60Hz, 4K 60/120/144Hz, 1440p 240Hz DP 1.4 Alt Mode, and Power Delivery 3.0; Universal compatibility w/USB-C; Backward compatible w/DP 1.2; Dock and charge a USB-C laptop over a single connection
DURABILITY AND BUILD QUALITY:
Flexible PVC outer jacket improves durability and protects from wear; Aluminum-mylar shield with metal connector housing for enhanced EMI protection; Nickel-plated connectors rated beyond 10,000 insertion cycles
PERFORMANCE:
USB 3.2 Gen 2 (10 Gbps); 8K 60Hz, 4K 60/120/144Hz, 1440p 240Hz w/DSC; DP 1.4 Alt Mode w/HBR3/HDR10/MST/DSC 1.2/HDCP 2.2; 60W PD 3.0; 9.8ft (3m); Black; 29AWG; 6.2mm O.D.; Compatible with USB-C laptops, mobile devices, and iPhone 15 / 15 Pro
Warranty Information
Warranty
2 Years
Connector(s)
Connector A
1 - USB 3.2 Gen 2 USB Type-C (Power Delivery + Data, 24 Pin, 10 Gbps)
Connector B
1 - USB 3.2 Gen 2 USB Type-C (Power Delivery + Data, 24 Pin, 10 Gbps)
Environmental
Operating Temperature
0°C to 45°C (32°F to 114°F)
Storage Temperature
-10°C to 70°C (14°F to 158°F)
Humidity
10% to 85% RH (non-condensing)
Hardware
Active or Passive Adapter
Active
Connector Plating
Nickel
Cable Jacket Material
PVC
Cable Shield Material
Aluminum-Mylar Foil with Braid
Chipset ID
Analogix ANX7411, Analogix ANX7451
Packaging Information
Package Quantity
1
Package Height
1.3 in [3.2 cm]
Package Length
8.7 in [22.0 cm]
Shipping (Package) Weight
7.2 oz [204.0 g]
Package Width
7.9 in [20.0 cm]
Performance
Maximum Data Transfer Rate
10 Gbps
Maximum Digital Resolutions
8K 60Hz
Type and Rate
USB 3.2 Gen 2 - 10 Gbit/s
Supported Protocols
USB 3.2, USB 3.1, USB 3.0, DP Alt Mode 1.4
Physical Characteristics
Color
Black
Product Height
0.4 in [1.0 cm]
Product Length
9.8 ft [3.0 m]
Weight of Product
6.8 oz [194.0 g]
Product Width
0.6 in [1.5 cm]
Wire Gauge
29 AWG
Material
ABS
Cable Length
9.8 ft [3 m]
Cable OD
0.2 in [6.2 mm]
Power
Power Delivery
60W
Software
OS Compatibility
No Drivers or Software required
Special Notes / Requirements
Note
USB 10Gbps is also known as SuperSpeed USB 10Gbps, USB 3.2 Gen 2, USB 3.1 Gen 2, and USB 3.1.
What's in the Box
Included in Package
1 - USB-C Cable
