The Next Generation of Wi-Fi is Upon Us
Wi-Fi 6 (802.11ax) could turn out to be the most significant advancement in Wi-Fi development, delivering a huge boost in speed and total capacity. Mainstream adoption of Wi-Fi 6 is inching ever closer with more and more AX clients available. It's the right time to upgrade your router to the newest generation of Wi-Fi!
Lightning-Fast AX3000 Dual Band Wi-Fi
Upgrade your home or office network with the latest-generation of dual band 802.11ax access point, which offers combined speeds of up to 3000Mbps and is perfectly suited to serve multiple devices at the same time. The 5GHz band is ideal for Ultra-HD streaming video and online gaming, while the 2.4GHz band is there for all of your everyday Internet needs, like sending email and browsing the Internet.
Gigabit-Class Wired Performance
The gigabit Ethernet port makes full use of gigabit-class bandwidth provided by a local ISP to ensure reliable network connections. It also provides an ultra-fast connection for wired devices such as PCs, IPTVs, and game consoles, etc.
Boosted Wi-Fi Coverage
Four external antennas equipped with Beamforming technology concentrate Wi-Fi signals towards your devices to extend reliable Wi-Fi to every corner of your home or office—even over long distances.
Deploy Anywhere with Just One Cable
Power over Ethernet (PoE) allows your Ethernet cable to carry electrical power and data simultaneously, making deployment effortless and flexible. An elegant appearance and simple mounting design make it easy to attach the Access Point to any wall or desktop, blending in perfectly with most interior decoration.
Captive Portal Marketing
Captive Portal provides a secure guest network and offers unique marketing opportunities, especially for small businesses like cafes or salons. Utilize a flexibly designed portal page—requiring customers to view an advertisement or accept a set of terms for internet access—to improve brand awareness or deliver marketing messages.
Access Point Mode (Default Mode)
Extends your existing wired network and makes it wireless, allowing you to connect all of your Wi-Fi devices.
Multi-SSID Mode
Simultaneously supports up to four separate SSIDs and VLANs on each band, making it ideal for offices where departments with different access policies share a wireless network.
Range Extender Mode
Extend your existing wireless coverage by repeating the wireless signal.
Client Mode
Acts as a “Wireless Adapter” to connect your wired devices to a wireless network.
HARDWARE FEATURES
Interface
1 Gigabit Port (Supports Passive PoE)
Button
Power On/Off Button, WPS Button, Reset Button
External Power Supply
48V/0.5A
Dimensions ( W x D x H )
9.4×6.5×1.7 in (240×165×43.6mm)
Antenna Type
4 Fixed High Performance Antennas
WIRELESS FEATURES
Wireless Standards
IEEE802.11b/g/n/ax 2.4 GHz, IEEE 802.11a/n/ac/ax 5 GHz
Frequency
2.4 GHz and 5 GHz
Signal Rate
2402 Mbps at 5 GHz, 574 Mbps at 2.4 GHz
Reception Sensitivity
5 GHz:
11ax HE20 MCS0:-97dBm, 11ac VHT20 MCS9:-73dBm, 11ax HE20 MCS11:-67dBm
11ax HE40 MCS0:-94dBm, 11ac VHT40 MCS9:-70dBm, 11ax HE40 MCS11:-63dBm
11ax HE80 MCS0:-91dBm, 11ac VHT80 MCS9:-66dBm, 11ax HE80 MCS11:-60dBm
11ac VHT160 MCS9:-63dBm, 11ax HE160 MCS11:-58dBm
2.4 GHz:
11ac VHT20 MCS0:-97dBm, 11ac VHT20 MCS8:-73dBm, 11ax HE20 MCS11:-65dBm
11ac VHT40 MCS0:-93dBm, 11ac VHT40 MCS9:-69dBm, 11ax HE40 MCS11:-62dBm
Transmit Power
FCC: <23dBm(2.4GHz), <22dBm(5GHz)
Wireless Functions
Enable/Disable Wireless Radio, WMM, Wireless Statistics, Access Control
Wireless Security
WPA, WPA2, WPA3, WPA/WPA2-Enterprise encryptions
SOFTWARE FEATURES
Quality of Service
WMM
Operating Modes
Access Point, Range Extender, Client, Multi-SSID
System Tools
SNMP, Ping Watchdog
DHCP
Server, DHCP Client List
Protocols
IPv4, IPv6
OTHERS
Certification
FCC, RoHS
Package Contents
Wireless Access Point TL-WA3001
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
PoE Power Injector
System Requirements
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or
other JavaScript-enabled browser
Environment
Operating Temperature: 0°C ~ 40°C(32°F ~ 104°F)
Operating Humidity: 10%~90% non-condensing
