Description
Asustor AS6602T 2-Bay NAS, Intel Quad Core 2.0GHz, 2x M.2 2280 NVMe Slot, 4GB RAM (8GB Max), 2x 2.5GbE LAN, 1x HDMI, 3 Years Warranty
Power for the power user - Bringing Double Performance, and SSD Caching to the Small Business
- Two 2.5 GbE ports with up to 5 Gbps under Link Aggregation
- Dual M.2 NVMe SSD ports for fast caching
- Overwhelming 4K experience
- Intel Celeron quad core CPU - 30% faster than previous generation.
- 4GB DDR4-2400 - 30% faster than DDR3
- Supports Wake on LAN and Wake on WAN
All new hardware – Same great case
- Two 2.5 GbE ports with up to 5 Gbps under Link Aggregation
- Dual M.2 NVMe SSD ports for fast caching
- Overwhelming 4K experience
- Intel Celeron quad core CPU - 30% faster than previous generation.
- 4GB DDR4-2400 - 30% faster than DDR3
- Supports Wake on LAN and Wake on WAN
360° Backup solution and enterprise virtualization application
- MyArchive cold storage backups
- Snapshot Center, Cloud Backup Center, DataSync Center
- Complete iSCSI/IP-SAN and NFS support
- VMware, Citrix and Hyper-V ready
- Supports Virtualization and Docker apps
Powered by the latest Intel Celeron J4125 (Gemini Lake) quad-core processors
The Lockerstor 2 utilizes the Intel Gemini Lake Celeron J4125 Quad Core CPU and is 30% faster than Apollo lake. The Celeron J4125 also doubles the on-chip cache to 4MB, making the Lockerstor 2 one of our fastest NAS devices ever.
Upgradeable 4GB Dual-Channel DDR4-2400 RAM
The Lockerstor 2 comes with four Gigabytes of DDR4 RAM and can be upgraded up to 8GB. DDR4 RAM provides up to 30% greater performance than DDR3 while also lowering energy requirements by 40%.
150% Faster with 2.5-Gigabit Ethernet
The Lockerstor 2 provides two 2.5-Gigabit Ethernet ports. Enable up to 150% faster performance than Gigabit Ethernet with compatible hardware and up to 5 Gbps using Link Aggregation.**Link Aggregation only supported with compatible hardware. Please check beforehand and verify that Link Aggregation is supported on your equipment.
Easy M.2 SSD installation
Dual M.2 slots for NVMe SSDs for SSD Caching.
The Lockerstor 2 is the first two bay NAS with integrated M.2 SSD slots.
*M.2 2280 cards supported with installed mounting holes.
Two Bays with Two M.2 SSD Slots for Flexible Cached Storage
The Lockerstor 2 is a cost-effective high capacity NAS designed for enterprise environments. The Lockerstor 2 is flexible, supporting online capacity expansion and replacement. Online capacity expansion enables you to replace hard drives inside the NAS without downtime. If your budget and/or storage requirements are small, the Lockerstor 2 enables your NAS to grow alongside your needs by first purchasing smaller drives and then add more drives as you need. Additional drives can be purchased as your storage requirements grow and all drives can be fully replaced while continuing to use your NAS. Combining this with ASUSTOR’s MyArchive cold storage technology enables you to store a virtually unlimited amount of information.
24/7 Reliability and Durability
All ASUSTOR NAS are designed for and are suitable for 24/7 use. ASUSTOR NAS devices have also undergone rigorous tests, such as drop tests and burn tests to test durability in extreme conditions. Heatsinks were added to sensitive components to dissipate heat, helping to maintain the longevity of the device.
Protected From the Inside and Out
Protect your data from loss, damage and attacks with the Lockerstor 2 and 4. A Lockerstor is better protected by running the Linux-based ADM, employing a built-in firewall, ClamAV Antivirus, MyArchive and ADM’s various backup tools help protect ransomware even better.
Wake Up From Anywhere
The Lockerstor 2 and 4 feature Wake on WAN technology. No specialized equipment or settings are needed to wake the NAS. Simply use ASUSTOR’s wide variety of mobile apps, including but not limited to AiMaster, AiMusic, AiVideos and AiData to turn the NAS on or off remotely. Wake on WAN helps protect data by keeping the NAS powered off when not in use; thereby helping to prevent attacks, protects data integrity by remaining powered off during power failures and Wake on WAN also saves electricity, making for an even more efficient NAS.
Protected From Ransomware
The Lockerstor comes with the most up-to-date version of ADM to help protect against ransomware attacks. Snapshot Center and Btrfs provide the ability to efficiently create snapshots to protect and easily restore lost data. Other security features found on the Lockerstor are the ability to create one or more replacement administrator accounts, a firewall by ADM Defender that features blacklists and whitelists, the ability to change default ports, disable SSH and Terminal to prevent remote attacks. MyArchive cold storage hard drive security can also be increased by implementing AES 256bit encryption.
Comprehensive Backup Solutions
ASUSTOR’s comprehensive backup solution provides more than twelve backup options, including, but not limited to Amazon S3, Dropbox, Google Drive, and Onedrive. ASUSTOR Backup Plan for Windows as well as Time Machine for macOS provide easy backups for desktop and laptops while MyArchive removable hard drives provide long term storage. Btrfs is now supported and with Snapshot Center, can take snapshots of your information in the event of unintentional modification. Restore previous versions easily with Snapshot Center.
Virtual Storage
The ASUSTOR NAS provides enterprise-class hardware and software and is compatible with VMware, Citrix, Hyper-V virtual storage environments. iSCSI/IP-SAN and NFS support allow it to seamless integrate with existing IT environments, providing an optimal and cost-effective storage solution.
Exclusive MyArchive Cold Backup Technology
Unlimited Capacity Expansion
MyArchive cold storage technology turns NAS hard drives into removable storage archive drives. Directly insert a MyArchive hard drive into a free bay inside your NAS to easily access, backup and share terabytes of content.
Snapshot Center
Snapshot Center is a new feature for ASUSTOR NAS devices to utilize Btrfs and iSCSI volumes to take snapshots of the information inside a NAS. Snapshot Center supports up to 256 snapshots of a volume and can be done every five minutes, creating a backup that can be restored easily if data is damaged or lost.
MyArchive now supports Btrfs and snapshots. Btrfs for MyArchive supports snapshots and version history to help protect against accidental deletions or modifications.
DataSync Center
Datasync Center combines multiple cloud services into a single app. Datasync Center includes, but is not limited to Google Drive, Dropbox and Onedrive and supports multitasking as well as multiple accounts. Control your data with instant and scheduled backups as well as using Cloud Backup Center to create a hybrid cloud that keeps your data online and offline, keeping your data protected.
Cloud Backup Center
Combine multiple business cloud services:
Backblaze B2, Microsoft Azure Blob Storage, Alibaba Cloud
Instant backups and scheduled backups
Create a hybrid clouds to protect and secure your data from public cloud outages
Cross-Platform Multi-User Access
ASUSTOR NAS devices provide seamless cross-platform and multi-user access, allowing you to easily connect to your NAS from Windows, macOS or almost any device with a web browser no matter if it is a desktop, notebook, tablet or smartphone.
Custom Off-peak hours
Your time is important, so ADM provides a feature to ensure that your NAS performs at top speed when you want it to. Peak times enable your NAS to turn off certain background processes and maintenance at certain times of the day and are customizable while off-peak hours will return background processes to their normal state. Enable off-peak hours when the NAS is not actively being used, for example, when sleeping to ensure an optimal experience.
PhotoGallery + AiFoto 3.0
The all new Photo Gallery 3 and AiFoto 3 have been revamped and brings a variety of new features to make photo organization easier than ever. New features for Photo Gallery 3 include, but not are limited to custom folder selection, timelines, smart albums, and new photo modes. Easily blow up photos to up to twice their size, play songs on slideshows, performance enhancements and customized share links make for an even better photo viewing and sharing experience.
ASUSTOR Live
Your own streaming center. Stream your from a phone or tablet as well as a computer to multiple streaming platforms, Including, but not limited to YouTube, Twitch, Mixer or RTMP compatible platforms. Unlike services like restream.io, ASUSTOR Live doesn’t require fees to operate to stream to multiple platforms and channels which saves you money and streaming resources. Recordings can be safely saved to your NAS for future use.
Virtual Applications with Virtualbox
Deploy all kinds of operating systems to your NAS.
ADM 3.5 brings a newer Linux Kernel, providing better system security and stability.
Virtual Applications with Linux Center
ASUSTOR NAS users can now run the native Linux® system on their NAS, enjoying the rich variety of Linux® apps. Linux Center features easy installation without extra configurations. It effectively turns the NAS into a computer with unlimited possibilities.
Mobile Apps
ASUSTOR’s exclusive EZ-Connect technology allows you to connect to your NAS from anywhere with your Android or iOS device to securely access, download, upload and share files and information. ASUSTOR mobile apps securely protect your privacy and data by requiring passwords in order to protect your privacy and data. You can also make use of HTTPS connections for even more added security.
CPU
CPU Model
Intel Celeron J4125
CPU Architecture
x64 64-bit
CPU Frequency
Quad Core 2.0GHz (burst up 2.70 GHz)
Memory
Memory
4GB SO-DIMM DDR4
Memory Module Pre-installed
4GB (1 x 4GB)
Total Memory Slots
2
Memory Expandable up to
8GB (2 x 4GB)
Support mixed capacity
Flash Memory
8GB eMMC
Storage
HDD
2 x SATA3 6Gb/s; 3.5"/2.5" HDD/SSD
M.2 Drive Slots (SSD Cache)
2x M.2 PCIe (NVMe)
*M.2 2280
Maximum Internal Raw Capacity
32 TB (16 TB HDD X 2, Capacity may vary by RAID types)
Maximum Drive Bays with Expansion Unit
14
Maximum Raw Capacity with Expansion Units
224 TB (16 TB HDD X 14, Capacity may vary by RAID types)
External Ports
Expansion
USB 3.2 Gen 1 x3
Network
2.5 Gigabit Ethernet x 2
HDMI Output
HDMI 2.0a x1
Others
System Fan
70mm x 1
Infrared Receiver
Yes
Power Supply Unit / Adapter
65W x1
Input Power Voltage
100V to 240V AC
Certification
FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC
Operation
Power Consumption
15.9 W (Operation);
9.2 W (Disk Hibernation);
0.66 W (Sleep Mode)
Noise Level
17.7dB (HDD idle)
Operation Temperature
0°C~40°C (32°F~104°F)
Humidity
5% to 95% RH
Size and Weight
Size
163.5(H) x 108(W) x 230(D) mm
Weight
2 kg / 4.4 lb
