Synology DiskStation DS923+ 4-Bay NAS Server, AMD Ryzen R1600 Dual Core Upto 3.1 GHz
DiskStation DS923+
Flexible storage platform for small businesses and home offices
Take your data management to the next level
Versatile smart storage that helps you consolidate and store your growing digital data.
Stunningly compact
Powerful functionality in a tiny package, with room for 10GbE and dual NVMe drives.
Consolidate and share
Flexibly store and organize 50 TB of data, then share with anyone.
Keep your data safe
Hardware and software engineered to protect your data - trusted by millions.
Storage that fits your needs
Is your data scattered across external drives and public cloud accounts? With the DS923+, you can consolidate your data with over 50 TB across 4 bays.[1] Need more space? Expand with the DX517 for over 120 TB of storage.
The performance you need
Reduce transfer times with the DS923+, designed to accelerate your workloads. Easily add faster networking and NVMe drives to further boost performance.
Store, share, and protect
Manage all your documents, photos, and other files, back up applications and devices, and protect your assets with professional video surveillance.
Consolidate data management
A private cloud for all your devices - Build your own personal cloud with Synology's private cloud solution. Simplify file access and consolidate your data management to benefit from easier file sharing and collaboration.
Professional photo management - Efficiently back up and organize photos and videos with management tools for amateurs and professionals. Automatically organize your content into albums and create secure share links for family, friends, or clients.
Collaborate across sites
Sync files and folders between sites - Site-to-site file syncing allows collaborators to sync individual files or folders between Synology devices, whether at home, another office, or across the world. Combine convenient access with 100% data ownership.
Share data with the power of the cloud - Reduce your on-site storage footprint and benefit from data center network speeds with hybrid cloud technology. Set up Hybrid Share Folders to efficiently store cold data in the cloud, while keeping frequently accessed files cached locally on your DS923+ and accessible at LAN speeds.
Back up all your devices
Centralize your backup and recovery solution - Consolidate and automate backup tasks for PCs, file servers, VMs, SaaS applications, and more with the Active Backup Suite. Manage device backups remotely through a centralized portal and quickly restore specific files or whole devices to keep your business up and running. Built-in remote backup solutions enable seamless 3-2-1 backup configurations.
Protect your Synology system
Perform full Synology system backups - Protect all data, applications, and configurations on your Synology systems with comprehensive scheduled backups to local and remote servers, external drives, or cloud storage destinations including Synology C2 Storage.[5]
Protect folders and LUNs with snapshots - Configure efficient point-in-time snapshots of shared folders and LUNs at intervals as short as 5 minutes. Allow users to easily restore previous versions of files unassisted, quickly recover VMs, and copy snapshots to another server to benefit from rapid storage failover.
Monitor and protect your business
Synology Surveillance Station - Protecting your business has never been easier, with centralized management, support for over 8,300 IP camera models, and remote monitoring and playback. Synology's video management system provides all the tools you need for live monitoring, investigation, management, and backup.[6]
Back up your surveillance footage
Dual recording - C2 Surveillance allows you to keep access to surveillance footage if your recording server is disabled by recording to your local server as well as C2 cloud. End-to-end encryption protects streams against unauthorized access while low latency recording lets you review the crucial last few seconds before the recording server was lost.
Ports
1. Storage figure calculated based on a RAID 5 configuration. Total storage capacity may vary depending on hard drives used and RAID configuration.
2. Performance figures are obtained through internal testing by Synology. Actual performance may vary depending on the testing environment, usage, and configuration. See performance charts for more information.
3. PCIe add-in cards, expansion units, and storage drives are sold separately. Refer to the compatibility list for compatible devices.
4. Synology SNV3400 series M.2 NVMe SSD drives can be installed through the built-in M.2 slots to enable SSD caching or create SSD storage pools. Drives are sold separately.
5. C2 Storage for Hyper Backup and Hybrid Share requires purchase of an eligible annual or monthly subscription. A free trial is available for each newly registered account.
6. Surveillance Station includes 2 free licenses. Connecting more cameras and devices requires additional licenses.
7. The warranty period starts from the date of purchase as stated on your purchase receipt. Visit https://www.synology.com/company/legal/warranty for more information.
CPU
CPU Model
AMD Ryzen R1600
CPU Quantity
1
CPU Architecture
64-bit
CPU Frequency
2-core 2.6 (base) / 3.1 (turbo) GHz
Hardware Encryption Engine (AES-NI)
Yes
Memory
System Memory
4 GB DDR4 ECC
Memory Module Pre-installed
4 GB (4 GB x 1)
Total Memory Slots
2
Maximum Memory Capacity
32 GB (16 GB x 2)
Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
Drive Bays
4
Maximum Drive Bays with Expansion Unit
9 (DX517 x 1)
M.2 Drive Slots
2 (NVMe)
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA SSD
M.2 2280 NVMe SSD
Hot Swappable Drive*
Yes
Notes
The hot swappable drive feature is not supported by M.2 SSD slots.
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports
RJ-45 1GbE LAN Port*
2 (with Link Aggregation / Failover support)
USB 3.2 Gen 1 Port*
2
eSATA Port
1
Notes
This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
PCIe
PCIe Expansion
1 x Gen3 x2 network upgrade slot
File System
Internal Drives
Btrfs
EXT4
External Drives
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT
Notes
exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center.
Appearance
Size (Height x Width x Depth)
166 mm x 199 mm x 223 mm
Weight
2.24 kg
Others
System Fan
92 mm x 92 mm x 2 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators
Yes
Power Recovery
Yes
Noise Level*
22.9 dB(A)
Scheduled Power On / Off
Yes
Wake on LAN / WAN
Yes
Power Supply Unit / Adapter
100 W
AC Input Power Voltage
100V to 240V AC
Power Frequency
50/60 Hz, Single Phase
Power Consumption
35.51 W (Access)
11.52 W (HDD Hibernation)
British Thermal Unit
121.09 BTU/hr (Access)
39.28 BTU/hr (HDD Hibernation)
Notes
For more information on how power consumption is measured, refer to this article.
Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle stae. Two G.R.A.S. Type 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75°C; Humidity: 58.2-61.8%
Temperature
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-20°C to 60°C (-5°F to 140°F)
Relative Humidity
5% to 95% RH
Warranty
Warranty
3-year hardware warranty, extendable to 5 years with EW201
Notes
Availability varies by region. Before purchasing, please visit the official web pages of EW201/202 and Extended Warranty Plus for a list of eligible regions.
The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Packaging Content
Items included
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 2
Quick Installation Guide X 1
Standard
Certification
FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
Environment
RoHS Compliant
Optional Accessories
DDR4 ECC SODIMM: D4ES02-4G/D4ES02-8G/D4ES01-16G
Expansion Units: DX517
3.5" SATA HDD: HAT5300
2.5" SATA SSD: SAT5210
M.2 2280 NVMe SSD: SNV3410
10GbE Network Upgrade Module: E10G22-T1-Mini
VisualStation: VS360HD
