Cellular 4G router for industrial IoT applications, supporting serial interfaces RS232 and RS485, MQTT, BACnet, I/Os, Ethernet, and more. This cellular router is equipped with GNSS and failsafe features such as Dual SIM, auto-failover, and backup WAN.
CONNECTIVITY
4G LTE (Cat 4), 3G, 2G
DUAL SIM
Auto-failover, backup WAN, and more switching scenarios
INTERFACES & PROTOCOLS
Serial interfaces (RS232 & RS485), MQTT, BACnet, OPC UA, I/Os, Ethernet, and more
GNSS
NTRIP, location services and time synchronization
Mobile
4G (LTE) – Cat 4 up to 150 Mbps, 3G – Up to 42 Mbps, 2G – Up to 236.8 kbps
CPU
Mediatek, 580 MHz, MIPS 24KEc
Memory
128 MB, DDR2
Storage
16 MB, SPI Flash
Powering Options
4-pin industrial DC power socket, 9 - 30 VDC
SIM
2 x SIM slots (Mini SIM - 2FF), 1.8 V/3 V, external SIM holders, eSIM (Optional)
SD Card
Micro SD (internal)
Antenna Connectors
2 x SMA for LTE, 2 x RP-SMA for Wi-Fi, 1 x SMA for GNSS
Ethernet
4 x 10/100 Ethernet ports: 1 x WAN (configurable as LAN), 3 x LAN
Wi-Fi
IEEE 802.11b/g/n, Access Point (AP), Station (STA)
GNSS
GPS, GLONASS, BeiDou, Galileo and QZSS
Inputs/Outputs
2 x Inputs and 2 x Outputs on 10-pin industrial socket, 1 x Digital input and 1 x Digital output on 4-pin power connector
Serial
1 x RS232, 1 x RS485
Other
1 x USB host
Status LEDs
1 x bi-color connection status, 5 x Mobile connection strength, 4 x ETH status, 1 x Power
Operating Temperature
-40 °C to 75 °C
Housing
Aluminium housing, plastic panels
Dimensions (W x H x D)
109.5 x 50 x 100 mm
Weight
295g
