Upgrade to a Super-Fast, Futuristic Network
5/8-Port 2.5G Desktop Switch
Unlock the Highest Performance of 2.5G Multi-Gig Bandwidth and Devices
As the flagship 2.5G products, the 5/8-Port desktop switches with 5/8x 2.5-Gigabit ports unlock the highest performance of your Multi-Gig bandwidth and devices, and provide up to 25/40 Gbps of switching capacity. Auto-negotiation 3-speed (100Mb/1G/2.5G) connections sense the link speeds and intelligently adjust for compatibility and optimal performance for all your devices, including 2.5G NAS, 2.5G PCIe adapter, gaming console, VR gaming, 2.5G WiFi 6 AP, 4K video, desktop, and more.
Ready for Immediate Network Upgrading to 2.5G?
Powerful Performance for Smooth LAN Parties
Never host a laggy LAN party again. Experience the unparalleled speed and lower latency, and prioritize gaming traffic with QoS. Let's begin the unprecedented smooth game!
Enjoy Buffer-Free 4K Videos
Enjoy buffer-free multi-channel 4K videos with friends and family for movie nights with maximum entertainment.
More 2.5GE LAN Ports for WiFi 6 Networking
Expand the 2.5GE LAN ports of your WiFi 6 routers and connect more devices-all running at max 2.5Gbps.
Unlock the Real WiFi 6
The best option to meet the full bandwidth potential of WiFi 6 access points with 2.5G wired connections.
Instant Transfer for Workstations
Immediately back up and store computer files to NAS storage with increased transfer speeds, never waste time.
2.5G Super-Fast Speeds without Changing Cables
Flawlessly integrated into existing gigabit Ethernet network infrastructures, 2.5x faster speeds* with regular Cat5e Ethernet cables, without the need to upgrade to Cat6 wiring, reducing wiring costs and hassle.
*2.5x faster speeds refers to the speeds compared to standard 1G ports. The actual speeds may vary due to the cable quality and type, client limitations, and environmental factors.
Silent Operation with Industry-Leading Fanless Design
The revolutionary fanless design ensures unprecedented silent operation, ideal for any home or business. Durable metal casing, desktop/wall-mounting design and professional heat dissipation design are well-suited for different environments.
Just Plug and Play for Internet Access
A plug-and-play design allows for easy deployment without the need for a technician. Auto MDI/MDIX eliminates the need for crossover cables.
Flexible Deployment Options
The versatile mounting system gives you the flexibility to place the 2.5G switch on a desktop or mount it to a wall.
HARDWARE FEATURES
Standards and Protocols
IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, 802.3bz
Interface
5× 100Mbps/1Gbps/2.5Gbp Ports, Auto-Negotiation, Auto-MDI/MDIX
Fan Quantity
Fanless
External Power Supply
External Power Adapter (Output: 12 VDC / 1 A)
LED Indicator
System Power: 1
Link/Act Indicators: 5, 1 indicator per port built into each RJ-45 port
Dimensions ( W x D x H )
8.2×4.9×1.0 in (209×126×26 mm)
Max Power Consumption
12.11 W
Max Heat Dissipation
41.32 BTU/h
PERFORMANCE
Switching Capacity
25 Gbps
Packet Forwarding Rate
18.6 Mpps
MAC Address Table
16 K
Packet Buffer Memory
1.5 Mb
Jumbo Frame
10 KB
SOFTWARE FEATURES
Advanced Features
802.3X Flow Control
802.1p/DSCP QoS
Transfer Method
Store and Forward
OTHERS
Certification
CE, FCC ,RoHS
Package Contents
5-Port 2.5G Multi-Gigabit Desktop Switch TL-SG105-M2
Power Adapter
Installation Guide
Rubber Feet
Environment
Operating Temperature: 0-40 °C (32-104 °F)
Storage Temperature: -40-70 °C (-40-158 °F)
Operating Humidity: 10-90% RH non-condensing
Storage Humidity: 5-90% RH non-condensing
