- Model
- BR15 R2R
- Color
- Silver
- Hardware solution
- Master control: ESP32-S3; DAC: FIIO proprietary R2R DAC; USB decoding: XU316; Bluetooth decoding: QCC5181
- Working mode
- USB DAC mode/Coaxial decoding mode/Optical decoding mode/Bluetooth receiving mode
- Weight
- About 760g
- Dimensions
- About 210x188x42mm (including feet)
- Volume control
- Knob/Remote control
- Remote control
- Supports IR remote control (only the one included in the accessory)
- Drive-free mode (switch mode)
- Supported
- FIIO Control
- Supported
- Oversampling setting
- OFF/96K/192K/384K
- Bluetooth reception (5.4)
- LC3/SBC/AAC/aptX/aptX HD/aptX Adaptive/LDAC/aptX Lossless
- MQA
- Supports MQA full decoding (PEQ=OFF)
- PEQ
- Supports 10-band PEQ
- Display
- 1.47-inch LCD
- Knob indicator light
- Supports customizing color, brightness, supports always-on indication or RGB pulsing
- Max. supported sampling rate (PEQ=OFF)
- USB decoding: 384kHz/32bit; DSD256
- Coaxial decoding: 192kHz/24bit; DSD64
- Optical decoding: 192kHz/24bit; DSD64
- Coaxial output: Up to 192kHz/24bit; DSD64
- Optical output: Up to 192kHz/24bit; DSD64
- Screen status indication
- Sampling rate, volume, EQ, Bluetooth codec, working mode, etc.
- Firmware upgrade
- MCU firmware: Upgrade through the front USB-C port
- XMOS firmware: Upgrade through the front or rear USB-C port
- Bluetooth firmware: Upgrade through the FIIO Control app
- Knob
- Menu knob with button*1+Volume knob with button*1
- USB port
- Type-C USB*2 (Data transmission port)
- Digital coaxial input/output port
- RCA port (shared input/output)
- Digital optical input port
- Optical port
- Balanced line output port
- XLR3 balanced port
- Digital optical output port
- Optical port
- Single-ended line output port
- RCA port*2
- Physical button
- Power button
- Power supply
- AC 100-240V~50/60Hz; DC 5V/=2A (either-or)
- Battery capacity
- No battery
- THD+N
- About 0.017% (1kHz/0dB @ 10KO)
- SNR
- =116dB (A-weighted)
- Crosstalk
- =110dB
- Noise floor
- <3.3uV (A-weighted)
- Frequency response
- 20Hz~20kHz: attenuation<0.2dB
- 20Hz~65kHz: attenuation<2.9dB
- Dynamic range
- =110dB
- Line output level
- 2.2Vrms (1kHz @ 10kO)
- THD+N
- About 0.015% (1kHz/0dB @ 10KO)
- SNR
- =119dB (A-weighted)
- Crosstalk
- =112dB
- Noise floor
- <5.1uV (A-weighted)
- Frequency response
- 20Hz~20kHz: attenuation<0.2dB
- 20Hz~65kHz: attenuation<2.9dB
- Dynamic range
- =112dB
- Line output level
- 4.4Vrms (1kHz @ 10kO)
