- Sampling frequencies
- 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
- Quantization bit depth
- 24-bit
- Mic inputs (balanced)
- XLR-3-31 equivalent
- (1: GND, 2: HOT, 3: COLD)
- Mic Input impedance
- 2.2 kOhms
- Mic Rated input level
- -7 dBu (0.346 Vrms)
- Mic Maximum input level
- +9 dBu (2.183 Vrms)
- Mic Gain range
- 56 dB
- Instrument inputs (unbalanced, MIC/LINE INST switch set to INST)
- 6.3-mm standard TS stereo jacks
- (Tip: HOT, Sleeve: GND)
- Instrument Input impedance
- =>1 MOhms
- Instrument Rated input level
- -6 dBV (0.501 Vrms)
- Instrument Maximum input level
- +10 dBV (3.162 Vrms)
- Instrument Gain range
- 56 dB
- Line inputs (balanced, MIC/LINE INST switch set to MIC/LINE)
- 6.3-mm standard TRS stereo jack
- (Tip: HOT, Ring: COLD, Sleeve: GND)
- Line Input impedance
- 10 kOhms
- Line Rated input level
- +4 dBu (1.228 Vrms)
- Line Maximum input level
- +20 dBu (7.75 Vrms)
- Line Gain range
- 56 dB
- Line outputs (balanced)
- 6.3-mm standard TRS stereo jacks
- (Tip: HOT, Ring: COLD, Sleeve: GND)
- Line Output impedance
- 210 Ohms
- Line Rated output level
- +4 dBu (1.228 Vrms)
- Line Maximum output level
- +20 dBu (7.746 Vrms)
- Headphone output (PHONES)
- 6.3-mm standard stereo jack
- Headphone Maximum output power
- 45 mW + 45 mW or higher (THD+N 0.1% or less, into 32 Ohms load)
- MIDI IN connector
- 5-pin DIN
- MIDI IN Format
- MIDI standard
- MIDI OUT connector
- 5-pin DIN
- MIDI OUT Format
- MIDI standard
- USB
- 4-pin USB, Type C
- USB Transfer rate
- USB 2.0 High Speed (480 MBit/s)
- Mic amp EIN (equivalent input noise)
- =<-128 dBu (150 Ohms termination, GAIN knob at maximum)
- Frequency response, MIC/LINE input
- 44.1 kHz / 48 kHz: 20 Hz - 20 kHz, +0 dB/-0.4 dB (JEITA)
- 88.2 kHz / 96 kHz: 20 Hz - 40 kHz, +0 dB/-0.4 dB (JEITA)
- Frequency response, LINE output
- 44.1 kHz / 48 kHz: 20 Hz - 20 kHz, +0.2 dB/-0.1 dB (JEITA)
- 88.2 kHz / 96 kHz: 20 Hz - 40 kHz, +0.2 dB/-0.4 dB (JEITA)
- Computer hardware requirements
- Windows computer with a USB 2.0 port
- CPU/processor speed
- 2 GHz or faster dual core processor (x86)
- Memory
- 2 GB or more
- Note
- Operation of this unit was confirmed using standard computers that meet the above requirements. This does not guarantee operation with all computers that meet the above requirements. Even computers that meet the same system requirements might have processing capabilities that differ according to their settings and other operating conditions
- Supported audio drivers
- ASIO2.0, WDM, MIDI
- CPU/processor speed
- 2 GHz or faster dual core processor
- Memory
- 2 GB or more
- Supported audio drivers
- Core Audio, Core MIDI
- Supported audio drivers
- Core Audio
- Note
- To connect an iOS device that has a Lightning connector, a genuine Apple Lightning to USB Camera Adapter (sold separately) is necessary.
- Power supply when used with a computer
- USB bus power or dedicated AC adapter below
- Power supply when used with an iOS device
- Dedicated AC adapter (Tascam PS-P1220E, DC 12 V)
- Power consumption
- 2.25 W
- External dimensions (W x H x D, including protrusions)
- 296 mm x 65 mm x 160 mm
- Weight
- 1.6 kg
- Operating temperature range
- 5-35 °C
