DJI RS 5 features touchscreen subject selection with the new tracking module [1], smooth balancing from fine-tuning knobs, and direct control via the new briefcase handle [2]—all backed by faster charging and extended battery life [3].
- Enhanced Intelligent Tracking and Composition [1]
- Briefcase Handle With Gimbal & Camera Control [2]
- 1-Hour Full Charge, 15% Extended Runtime [3]
- Fine-Tuning Knobs and Teflon™ Enhanced Balancing
- New Z-Axis Indicator
- 2nd-Gen Automated Axis Locks
RS Enhanced Intelligent Tracking Module
The module [1] lets you frame and track any subject [1] from the gimbal's touchscreen, keeping it precisely positioned. And when tracking a person, it offers a range of up to 10 meters and can reacquire the subject if they temporarily leave the frame.
Next-Gen Algorithm, Enhanced Torque
Peak motor torque is up by 50% over the previous model, offering stability in fast-moving scenes. The 5th-Gen RS Stabilization Algorithm further enhances stabilization for walking, running, and vertical shooting, striking an ideal balance between stability and control.
Compact Body With up to 3kg Payload
The gimbal weighs just 1.46 kg with battery grip and quick-release plates, and switches to vertical shooting without extra accessories. With a robust 3 kg (6.6 lbs) payload capacity, it can carry mainstream mirrorless camera and lens combinations [4] with ease.
New Electronic Briefcase Handle [2]
The new Electronic Briefcase Handle [2] offers intuitive, effortless single-handed operation, featuring a joystick and buttons that control the gimbal and camera for more creative angles.
Longer Runtime, Fully Charged in 1 Hour [3]
Fully charge DJI RS 5 in just one hour—a 60% increase in speed. The standard battery delivers approximately 14 hours of standby time, a 15% improvement [3].
DJI RS BG70 High-Capacity Battery Grip
The new BG70 High-Capacity Battery Grip [5] can extend RS 5's battery standby time to 30 hours [6].
New Bluetooth Shutter Support for Panasonic & Fujifilm
In addition to cameras from Sony, Canon, and Nikon, the RS 5's Bluetooth shutter now supports specific Panasonic and Fujifilm cameras [7], enabling wireless control of shutter, zoom, and Clear Image Zoom with no cables required.
Z-Axis Indicator
The new Z-Axis Indicator gives you instant feedback to fine-tune your footsteps for steadier, more professional shots.
Smooth & Precise Balancing
Fine-tuning knobs on each axis arm enable quick, precise balancing through a leadscrew mechanism. Combined with Teflon™ interlayers, RS 5 delivers smooth and precise balancing even with heavier professional setups.
2nd-Gen Automated Axis Locks
The 2nd-Gen Automated Axis Locks automatically lock the gimbal upon power-off or sleep for easier transitions and storage. They unlock just as quickly upon power-on, getting you ready to film in an instant for those critical moments.
3rd-Gen Native Vertical Shooting
To switch to vertical shooting, simply loosen and press the single-side knob, remove the gimbal's horizontal plate, rotate it 90°, and then tighten it back in place [8]—all in just a few seconds.
Dual-Layered Quick-Release Plates
The Arca-Swiss upper plate and Manfrotto lower plate allow quick switching between gimbal and tripod without rebalancing, thanks to position memory. In addition, the upper plate adds an adjustable guide for secure camera mounting.
Support for DJI Focus Pro Motor
When paired with two Focus Pro Motors [5], RS 5 allows cinematographers to adjust the lens zoom via the joystick and precisely control the focus via the dial, facilitating smooth and effortless lens control.
Support for DJI SDR Transmission
Both independent cinematographers and small crews can utilize the DJI SDR Transmission [5] for high-definition live feeds, remote gimbal and camera control, Force Mobile, and more.
RSA Communication Port
The RSA port connects to the Electronic Briefcase Handle, RS Tethered Control Handle [5], and remote-control ring handles [5]. The open RS SDK also lets third-party developers create custom functions.
Peripheral
Accessory Port
Ronin Series Accessories (RSA)/NATO Ports
1/4"-20 Mounting Hole
Cold Shoe
Camera Control Port (USB-C)
Multifunctional Port (USB-C)
Battery
Model: BHX715-2150-15.48
Type: LiPo 4S
Capacity: 2150 mAh
Energy: 33.29 Wh
Voltage: 11.2 V to 17.8 V
USB Input: 5 V/3 A, 9 V/3 A, 12 V/3 A, 15 V/3 A, 20 V/3 A
Max Standby Time: Approx. 14 hours*
Charging Time: Approx. 1 hour**
Suggested Charging Temperature: 5° to 40° C (41° to 104° F)
Connections
Bluetooth 5.0
USB-C Charging Port
Ronin App Requirements
iOS 14.0 or above
Android 9.0 or above
Languages Supported by the Touchscreen
English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai
Working Performance
Tested Payload
3.0 kg (6.6 lbs)
Maximum Controlled Rotation Speed
Pan: 360°/s
Tilt: 360°/s
Roll: 360°/s
Mechanical Range
Pan Axis: 360° continuous rotation
Roll Axis: -95° to +240°
Tilt Axis: -112° to +214°
Axis Lock
Auto
Vertical Shooting
Supported
Mechanical & Electrical Properties
Operating Frequency
2.4000-2.4835 GHz
Bluetooth Transmitter Power
< 8 dBm
Operating Temperature
-20° to 45° C (-4° to 113° F)
Weight
Gimbal: Approx. 1193 g (2.63 lbs) (including the Upper and Lower Quick-Release Plates and screws)
Grip: Approx. 274 g (0.6 lbs)
Quick-Open Tripod: Approx. 149 g (0.3 lbs)
Upper and Lower Quick-Release Plates: Approx. 93 g (0.21 lbs) (including screws)
Dimensions
Folded: 247.4×115.7×258.7 mm (L×W×H, excluding camera, grip, and Quick-Open Tripod)
Unfolded: 223.2×192.2×418.8 mm (L×W×H, including grip, excluding camera and Quick-Open Tripod)
Accessories
DJI RS Enhanced Intelligent Tracking Module
Weight: Approx. 19 g (0.04 lbs)
Dimensions: 35.9×17.5×38.5 mm (L×W×H)
Tracking Distance: 0.5-10 m
Operating Environment: Illuminance > 20 lux
Trigger Modes: Gimbal trigger, gesture, gimbal touchscreen
Gesture Functions: Start/stop of tracking, start/stop of recording, framing adjustment
Power Consumption: Approx. 1 W
Operating Temperature: -10° to 45° C (14° to 113° F)
Mounting Method: Magnetic attachment
Electronic Briefcase Handle
Weight: Approx. 149 g (0.33 lbs)
Dimensions: 60×197.5×79.5 mm (L×W×H)
Standby Power Consumption: Approx. 0.2 W
Operating Temperature: -20° to 45° C (-4° to 113° F)
