- Image Sensor
- 1/2.7" Progressive Scan CMOS
- Shutter Speed
- 1/3 to 1/10000 s
- Slow Shutter
- Yes
- Minimum Illumination
- 0.005 Lux; 0 Lux with IR/White Light
- Day/Night Mechanism
- IR Cut Filter
- Day/Night Switch
- Auto
- Type
- Fixed Focal Lens
- Focal Length
- 4 mm
- Aperture
- F1.6
- FOV
- Horizontal FOV: 88.0°
- Vertical FOV: 46.0°
- Diagonal FOV: 105.4°
- Lens Mount
- M12
- DORI Distance
- 4 mm:
- D: 351 ft (107 m)
- O: 144 ft (44 m)
- R: 69 ft (21 m)
- I: 36 ft (11 m)
- Angle Adjustment (Manual) @ Range
- Pan: 0° to 360°, Tilt: 0° to 85°, Rotation: 0° to 360°
- IR LED
- Quantity: 4
- Range: 98 ft (30 m)
- IR Wavelength: 850 nm
- White LED
- Quantity: 4
- Range: 98 ft (30 m)
- Illuminator On/Off Control
- Auto/Always on/Always off
- Max. Resolution
- 3840x2160
- Main Stream
- Frame Rate:
- 50Hz: 25fps (3840x2160, 2560x1440, 2304x1296, 2048x1280,1920x1080)
- 60Hz: 24fps (3840x2160, 2560x1440, 2304x1296, 2048x1280,1920x1080)
- Note:
- If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
- If 120dB WDR is turned on, the frame rate can only support up to 20fps.
- Sub-Stream
- Frame Rate:
- 50Hz: 25fps (840x480,704x576,640x480, 640x360, 352x288, 320x240)
- 60Hz: 24fps (840x480,704x576,640x480, 640x360, 352x288, 320x240)
- Note:
- If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
- If 120dB WDR is turned on, the frame rate can only support up to 20fps.
- Bit Rate Control
- CBR, VBR
- Video Compression
- Main Stream: H.265+/H.265/H.264+/H.264
- Sub-Stream: H.265/H.264
- H.264 Type
- High Profile
- H.264+
- Main Stream Supported
- H.265 Type
- Main Profile
- H.265+
- Main Stream Supported
- Video Bit Rate
- Main Stream: 256 Kbps to 8192 Kbps
- Sub-Stream: 64 Kbps to 1024 Kbps
- Image Settings
- Mirror
- Rotation
- Contrast
- Brightness
- Saturation
- Sharpness
- Exposure
- White Balance
- Image Enhancement
- BLC/3D DNR/SmartIR
- Wide Dynamic Range
- 120 dB
- SNR
- = 52 dB
- Image Parameters Switch
- Yes
- Privacy Mask
- Up to 4 Masks
- OSD Setting
- Yes
- Audio Communication
- Two-Way Audio
- Audio Input
- Yes (Built-in Microphone)
- Audio Output
- Yes (Built-in Speaker)
- Audio Compression
- Yes
- Audio Sampling Rate
- 8KHz, 16KHz
- Environment Noise Filtering
- Yes
- Audio Bit Rate
- 64 Kbps(G.711 alaw, G.711 ulaw)
- Protocol
- TCP/IP, UDP, ICMP, ARP, SMTP, RTMP, HTTP, HTTPS, DHCP, DNS, RTSP, RTP, NTP, IPv4, IPv6, UPnP, SSL/TLS, FTP/SFTP
- ONVIF
- Yes
- API
- Open Network Video Interface (Profile G/S/T)
- Simultaneous Live View
- 3 Main Streams & 10 Sub-Streams
- Client
- Web UI, Omada Guard App, Omada Cloud-Based Controller (Guard)
- Web Browser
- Google Chrome® 57 and above
- Firefox® 52 and above
- Safari® 11 and above
- Microsoft® Edge 91 and above
- Cloud
- Yes
- Security
- Password Protection, HTTPS Encryption, IP/MAC Restriction, Digest Authentication, 802.1X Authentication
- Event
- Motion Detection (Human Detection, Vehicle Detection, Pet Detection)
- Line Crossing Detection
- Intrusion Detection
- Camera Tampering
- Alarm Linkage
- Memory Card Video Recording
- Upload to FTP Server
- Push Notifications
- Active Defence-Sound Alarm
- Active Defence-Light Alarm
- Email Alarm
- Network Interface
- 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
- Reset Button
- Yes
- Power
- DC Power Port
- On-board Storage
- Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB*
- Built-in Microphone
- Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera
- Built-in Speaker
- Yes
- Operating Temperature
- -30 °C to 60 °C (-22 °F to 140 °F)
- Storage Temperature
- -40 °C to 60 °C (-40 °F to 140 °F)
- Operating Humidity
- 95% or Less (Non-Condensing)
- Storage Humidity
- 95% or Less (Non-Condensing)
- Package Content
- Omada Network Camera
- Waterproof Cable Attachments
- Network Cable (3 ft/1 m)
- Mounting Template
- Mounting Accessories
- Screwdriver
- GNU General Public License Notice
- Installation Guide
- Surveillance Sticker
- Material
- Metal
- Net Weight
- 0.5 kg
- Power Supply
- 12V DC ± 5%, Max. 12 W, 5.5 mm Coaxial Power Plug
- PoE: 802.3af/at, Max. 12.5 W
- Protection
- IP67 Weatherproof
- IK08 Vandal Proof
- Product Dimensions (L x W x H)
- 4.4 × 4.4 × 3.5 in (112 × 112 × 88mm)
- Certifications
- CE, NTRA, FCC, IP67, IK08, VCCI, BSMI, ONVIF
- Package Content
- Omada Network Camera
- Waterproof Cable Attachments
- Network Cable (3 ft/1 m)
- Mounting Template
- Mounting Accessories
- Screwdriver
- GNU General Public License Notice
- Installation Guide
- Surveillance Sticker
