- Ports
- 8 x RJ45 10/100/1000Base-T Gigabit Ports
- Button
- Reset Button
- LED Indicators
- Per Port : Link/Act
- Per Unit : Power
- Power Input
- External Power Supply (DC 5V/1A)
- Fan
- Fanless Design
- Dimensions (L x W x H)
- 155 x 85 x 26 mm
- Weight
- 325g
- Switching Capacity
- 16Gbps
- MAC Address
- 4K
- Jumbo Frames
- 9KB
- Buffer Memory
- 1.53Mb
- Transmission Method
- Store and Forward
- Filtering / Forwarding Rates
- Max. 11.9Mpps
- 1000Mbps port - 1,488,000pps
- 100Mbps port - 148,800pps
- 10Mbps port - 14,880pps
- Quality of Service (QoS)
- Port-based QoS,
- IEEE802.1p QoS,
- 4 Priority Queues,
- Scheduling Algorithm
- - WFQ (Weighted Fair Queue)
- - Strict Priority
- VLAN
- Up to 8 VLANs and 4096 VLAN IDs
- 802.1Q Tag-based VLAN
- Port Trunking
- IEEE 802.3ad LACP (Link Aggregation Control Protocol)
- Port Mirroring
- Port Mirroring both on Ingress and Egress Traffic
- IGMP Snooping
- IGMP Snooping v1/v2/v3
- Block Unknown Multicast Traffic
- Multicast Groups: 128
- Loop Detection
- Loop Detection
- Loop Prevention
- Security
- Broadcast Storm Control
- Management
- User Interface: Web-based Management
- User Account: Login Account Configuration
- Firmware Upgrade: Firmware Upgrade by WEB
- Standards
- IEEE 802.3 10BaseT Ethernet
- IEEE 802.3u 100BaseTX Fast Ethernet
- IEEE 802.3ab 1000BaseT Gigabit Ethernet
- IEEE 802.3x Full-duplex and Flow Control
- IEEE 802.3ad Link Aggregation Control Protocol (LACP)
- IEEE 802.3az Energy Efficient Ethernet
- IEEE 802.1Q VLAN
- IEEE 802.1p Quality of Service (QoS)
- Environmental Condition
- Operating temperature: 0 ~ 40? (32~104°F)
- Storage temperature: -40 ~ 70? (-40~158°F)
- ?Operating humidity: 10 ~ 90% (Non-condensing)
- Storage humidity: 5 ~ 90% (Non-condensing)
- Certifications
- CE, FCC, BSMI
