- Mobile module
- 4G LTE Cat 6 up to 300 DL/ 50 UL Mbps; 3G up to 42 DL/ 5.76 UL Mbps
- 3GPP Release
- Release 12
- SIM switch
- 2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection
- CPU
- MediaTek, Dual-core, 880 MHz, MIPS1004Kc
- RAM
- 256 MB, DDR3
- FLASH storage
- 16 MB serial NOR flash, 256 MB serial NAND flash
- Status
- IMSI, ICCID, operator, operator state, data connection state, network type, CA indicator, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC
- SMS
- SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
- USSD
- Supports sending and reading Unstructured Supplementary Service Data messages
- WAN
- 1 x WAN port 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards
- LAN
- 3 x LAN ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards
- Routing
- Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing
- Network protocols
- TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN
- VoIP passthrough support
- H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
- Connection monitoring
- Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection
- Firewall
- Port forward, traffic rules, custom rules, TTL target customisation
- USB Data rate
- USB 2.0
- Input
- 1 x Configurable digital Input, 0 - 6 V detected as logic low, 8 - 50 V detected as logic high
- Output
- 1 x Configurable digital Output, Open collector output, max output 50 V, 300 mA
- Events
- Email, RMS, SMS
- I/O juggler
- Allows to set certain I/O conditions to initiate event
- Power Connector
- 4-pin industrial DC power socket
- Input voltage range
- 9 - 50 VDC, reverse polarity protection, surge protection >51 VDC 10us max
- PoE (passive)
- Possibility to power up through LAN1 port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 50 VDC
- Power consumption
- Idle: < 2.65 W, Max: < 9.82 W
- I/O's
- 1 x Digital Input, 1 x Digital Output on 4-pin power connector
- Status LEDs
- 3 x WAN type LEDs, 3 x Mobile connection type, 5 x Mobile connection strength, 8 x LAN status, 1 x Power
- SIM
- 2 x SIM slots (Mini SIM - 2FF), 1.8 V/3 V, external SIM holders
- Antennas
- 2 x SMA for Mobile, 1 x SMA for GNSS
- Reset
- Reboot/User default reset/Factory reset button
- Casing material
- Anodized aluminum housing and panels
- Dimensions (W x H x D)
- 115 x 44.2 x 95.1 mm
- Weight
- 457 g
- Mounting options
- DIN rail, wall mount, flat surface (all require additional kit)
- Operating temperature
- -40 °C to 75 °C
- Operating humidity
- 10% to 90% non-condensing
- Ingress Protection Rating
- IP30
