- Dimensions
- 110 x 110 x 250 mm (4.3 x 4.3 x 9.8")
- UniFi Application Suite
- Network: Yes
- Protect: Yes
- Access: Yes
- Talk: Yes
- Connect: Yes
- Managed UniFi Devices
- 30+
- Managed Cameras
- (5) HD
- (2) 2K
- (1) 4K
- Simultaneous Users Connected
- 300+
- Max. WAN Port Count
- 4
- Default WAN Ports
- (1) 10G SFP+
- (1) 2.5 GbE RJ45
- Port Layout
- 2.5 GbE RJ45: 4 (1 PoE) (2.5G/1G/100M)
- 10G SFP+: 1 (10G/1G)
- IDS/IPS Throughput
- 2.3 Gbps
- Form Factor
- Desktop
- Coverage Area
- 160 m² (1,750 ft²)
- Stateful Firewall
- Yes
- Application-Aware Layer 7 Firewall
- Ye
- DPI & Traffic Identification
- Yes
- Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)
- Yes
- Content Filtering
- Yes
- Intrusion Prevention (IPS/IDS)
- Yes
- Ad Blocking
- Yes
- IDS/IPS Signatures
- 20,000+ with CyberSecure
- License-Free SD-WAN
- Yes
- Site-to-Site VPN
- Site Magic: Yes
- IPsec: Yes
- OpenVPN: Yes
- VPN Server
- Identity Endpoint One-Click VPN: Yes
- Teleport Zero-Configuration VPN: Yes
- WireGuard: Yes
- OpenVPN: Yes
- L2TP: Yes
- VPN Client
- OpenVPN: Yes
- WireGuard: Yes
- Site-to-Site VPN Single Tunnel Throughput
- Site Magic: 20
- VPN Client Single Tunnel Throughput
- WireGuard: 8
- OpenVPN: 8
- Multi-WAN Load Balancing
- Yes
- Dynamic Routing
- OSPF: Yes
- Advanced QoS
- Yes
- Multicast DNS (mDNS)
- Yes
- Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)
- Yes
- Integrated RADIUS Server
- Yes
- RADIUS over TLS (RadSec)
- Yes
- Additional Internet Failover with UniFi LTE Backup
- Yes
- Internet Quality and Outage Reporting
- Yes
- MAC Address Table Size
- 2,000
- Virtual Network Override
- Yes
- All Traffic Flows
- -
- WiFi Standard
- 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)
- Throughput
- 6 GHz:5.7 Gbps
- 5 GHz: 4.3 Gbps
- 2.4 GHz: 688 Mbps
- MIMO
- 6 GHz: 2 x 2 (DL/UL MU-MIMO)
- 5 GHz: 2 x 2 (DL/UL MU-MIMO)
- 2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
- Antenna Gain
- 6 GHz: 8 dBi
- 5 GHz: 5 dBi
- 2.4 GHz: 4 dBi
- Max. TX Power
- 6 GHz: 22 dBm
- 5 GHz: 26 dBm
- 2.4 GHz: 23 dBm
- Wireless Security
- WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
- Wireless Security
- WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
- Supported Data Rates
- 802.11be (WiFi 7): 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
- 802.11ax (WiFi 6/6E): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
- 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
- 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15 , HT 20/40)
- 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11b: 1, 2, 5.5, 11 Mbps
- 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 5G NR
- Category: 5G NR Sub-6
- Frequency Bands: n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n76, n77, n78, n79
- Max. TX Power: HPUE power class 2: 26 dBm
- 4G LTE
- Frequency Bands: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B18, B19, B20, B21, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71
- Max. TX Power: HPUE power class 2: 25 dBm
- 3G UMTS
- Frequency Bands: B1, B2, B4, B5, B8, B19
- Peak Data Speed
- 5G NSA
- Downlink 3.4 Gbps
- Uplink 560 Mbps
- 5G SA
- Downlink 1.8 Gbps
- Uplink 650 Mbps
- 4G LTE
- Downlink 1.6 Gbps
- Uplink 210 Mbps
- Antenna Gain
- 617-960 MHz: 3 dBi
- 1710-2700 MHz: 7 dBi
- 3300-5000 MHz: 8 dBi
- 5150~5925 MHz: 8 dBi
- SIM
- (2) Nano SIM
- (1) Nano-SIM or eSIM
- NVR Storage
- Pre-installed 64 GB microSD for NVR
- Expansion Slot
- MicroSD Card
- PoE Budget
- 15.4W
- Max. PoE Wattage per Port by PSE
- PoE: 15.4W
- Voltage Range PoE Mode
- 44-57V
- Max. Power Consumption
- 34.5W (Excluding PoE output)
- Power Method
- DC jack (54V DC/1.1A)
- Power Supply
- 54V DC/1.1A (Adapter included)
- Supported Voltage Range
- 100-240V AC
- Heat Dissipation
- 115 BTU/hr (Excluding PoE output)
- Processor
- Quad-core ARM® Cortex®-A53 at 1.5 GHz
- System Memory
- 3 GB
- Weight
- 1.4 kg (3.1 lb)
- Enclosure Material
- Polycarbonate
- LCM Display
- 4.7" touchscreen
- Management
- Ethernet
- Bluetooth
- LEDs
- Ethernet: Yes
- SFP+: Yes
- System: Yes
- Button
- (1) Factory reset
- ESD/EMP Protection
- Air: ± 8kV, contact: ± 4kV
- Ambient Operating Temperature
- 0 to 40° C (32 to 104° F)
- Ambient Operating Humidity
- 5 to 95% noncondensing
- NDAA Compliant
- Yes
- Certifications
- FCC, IC, CE, GCF, PTCRB, AT&T, T-Mobile, Wi-Fi Alliance®
- Application Requirements
- Mobile App
- UniFi iOS™: Version 10.33.0 and later
- UniFi Android™: Version 10.36.1 and later
