- Dimensions
- 212.9 x 113 x 32.5 mm
- (8.4 x 4.4 x 1.3")
- WiFi Standard
- WiFi 7
- Spatial Streams
- 4
- Mounting Locations
- Desktop, wall
- Power Method
- DC jack (54V DC/1.1A)
- Power Supply
- 54V DC/1.1A (Adapter included)
- MIMO
- 6 GHz
- 2 x 2
- 5 GHz
- 2 x 2
- Max. Data Rate
- 6 GHz
- 5.8 Gbps (BW320)
- 5 GHz
- 4.3 Gbps (BW240)
- Antenna Gain
- 6 GHz
- 8 dBi
- 5 GHz
- 8 dBi
- Max. TX Power
- 6 GHz
- 23 dBm
- 5 GHz
- 26 dBm
- Max. Conducted TX Power
- 26 dBm (Combined)
- Supported Data Rates
- 802.11be (WiFi 7)
- 6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320)
- 5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
- 802.11ax (WiFi 6)
- 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
- 802.11ac (WiFi 5)
- 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
- 802.11n
- 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
- 802.11a
- 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- Wireless Security
- WPA3 SAE (Always On)
- Max. Power Consumption
- 25W (Excluding PoE output)
- Supported Voltage Range
- 42.5-57V DC
- Networking Interface
- (1) 10 GbE RJ45 port
- (7) 2.5 GbE RJ45 ports
- PoE Interface
- (8) PoE+ ports
- Max. PoE Wattage per Port
- 30W
- Total PoE Availability
- 60W AC adapter input: 35W
- 210W AC adapter input: 185W
- Antennas
- (1) Internal
- Management
- Ethernet
- WiFi
- Channel Bandwidth
- 20/40/80/160/240/320 MHz
- Weight
- Device: 548 g (1.21 lb)
- With mount: 563 g (1.24 lb)
- Enclosure Material
- Polycarbonate
- Mount Material
- Polycarbonate
- LCM Display
- 0.96" status display
- Button
- (1) Factory reset
- NDAA Compliant
- Yes
- Certifications
- CE, FCC, IC
- Operating Frequency
- Worldwide:
- 5150-5875 MHz
- 5945-7125 MHz
- Ambient Operating Temperature
- -30 to 40° C (-22 to 104° F)
- Ambient Operating Humidity
- 5 to 95% noncondensing
- Application Requirements
- UniFi Network
- Version 10.0.156 or later.
